14 Technical Data SMA Solar Technology AG
72 SCxxxHE-20-IA-IEN111210 Installation Manual
Power consumption
Dimensions and weight
Efficiency
Ambient conditions
Self-consumption in operation < 1 500 W
Standby consumption < 100 W
External auxiliary supply voltage 3 x 230 V, 50 Hz / 60 Hz
Width x height x depth 2 404 mm x 2 092.5 mm x 936.5 mm*
* Without anchorage bracket in base, incl. crane cross-beam, depth incl. all attached components
Weight 1 670 kg
Maximum efficiency 98.6%
Euro-eta 98.4%
CEC-eta 98.5%
Degree of protection*
* As per DIN EN 60529
IP 21
Operating temperature range –20°C ... +50°C
Humidity 15% … 95%
Fresh air consumption 3 000 m³/h
Maximum altitude above sea level, MSL 2 000 m
