14 Technical Data SMA Solar Technology AG
70 SCxxxHE-20-IA-IEN111210 Installation Manual
14.4 Sunny Central 760HE
Input values
Output values
Power consumption
Dimensions and weight
Efficiency
MPP voltage range 554 V
DC
… 820 V
DC
Maximum DC voltage*
* Optional 1 100 V
1 000 V
DC
Maximum DC current 1 400 A
DC
Number of DC inputs 9
Nominal AC power at 50°C 760 kVA
Continuous AC power at 25°C 836 kVA
Maximum AC current 1 411 A
AC
Nominal AC current 1 283 A
AC
Nominal AC voltage ± 10% 342 V
AC
Grid frequency 50 Hz / 60 Hz
Power factor cosφ 0.9
overexcited
… 0.9
underexcited
Maximum total harmonic factor < 3%
Self-consumption in operation < 1 500 W
Standby consumption < 100 W
External auxiliary supply voltage 3 x 230 V, 50 Hz / 60 Hz
Width x height x depth 2 404 mm x 2 093 mm x 937 mm*
* Without anchorage bracket in base, incl. spreader beam, depth incl. all attached components
Weight 1 670 kg
Maximum efficiency 98.6%
Euro-eta 98.4%
CEC-eta 98.5%
