Safety SMA Solar Technology AG
6 BTPB-IEN112112 Installation Guide
2 Safety
2.1 Appropriate Usage
The communication interface allows you to establish a connection via Bluetooth wireless technology
to other SMA inverters and communication devices (e.g., Sunny Explorer).
The SMA Bluetooth Piggy-Back provides data of the inverter for configuring and creating daily,
monthly, and annual energy values. These can be accessed and configured using a communication
product (e.g., Sunny Explorer).
The SMA Bluetooth Piggy-Back is compatible with all SMA Bluetooth devices in terms of radio
frequency.
The interface is provided as an add-on kit or pre-installed in the inverter. Also observe the relevant
inverter manual.
The following inverters can be retrofitted with the SMA Bluetooth Piggy-Back:
• All Sunny Boys of type SB (with Piggy-Back port)
• SWR 2500
• All Sunny Mini Centrals of type SMC
• All Windy Boys of type WB
The communication interface complies with the following standards:
• R&TTE 1999 / 5 / EC
– EN 300 328-2, EN 301 489-17, EN 50371, EN 60950, EN301489-1
In addition, you will find a current overview of the standards at www.SMA.de/en. If you have any
questions, contact SMA Solar Technology.
Information
Information provides tips that are valuable for the optimal installation and operation of
your product.
Information on Configuring the Installation Country
All country standards that cannot be set through the SMA Bluetooth Piggy-Back can be set
through the USB service interface and Sunny Data Control or through RS485 and the
Sunny WebBox.
