SMA Solar Technology AG Update
Installation Guide BTPB-IEN112112 11
Setting the NetID
The NetID is set via the rotary coded switch on the SMA Bluetooth Piggy-Back.
1. Use a screwdriver (2.5 mm) to turn the arrow on the
rotary switch to the correct position. The meanings
of the switch positions are explained in the table.
2. Close the inverter as described in the inverter manual.
☑ The NetID is set. You can detect the inverter with a communication product (e.g. computer with
Sunny Explorer).
5 Update
The SMA Bluetooth Piggy-Back is updated through the Sunny Explorer. It is not required to replace
the Piggy-Back. Existing settings and data of the inverter will be saved after the update process. Only
perform the update if the inverter has a sufficient power output to the grid of at least 50 W. Restart
the Sunny Explorer if the update was successful.
Layout of the switch positions
NetID
Function
0 Bluetooth is switched off.
1 (Status upon delivery) Bluetooth is switched on.
The SMA Bluetooth Piggy-Back can only connect with a maximum of
2 computers with Sunny Explorer from SMA Solar Technology. A
connection to the Sunny Beam with Bluetooth is not possible.
2 - F Bluetooth is switched on.
The device can interlink with all SMA Bluetooth products with the same
NetID.
