SMA Solar Technology AG Safety
Installation Guide PModul-IEN094510 5
2 Safety
2.1 Appropriate Usage
The Power Modul enables the power supply of the SMA Bluetooth Repeater via the internal voltage
supply of SMA inverters of the type:
The Power Modul is exclusively suitable for use in the above mentioned SMA inverter types and for
the power supply of the following consumers:
• SMA Bluetooth Repeater
You receive the Power Modul as an upgrade kit. Please observe the respective manual of the inverter
and the manual of the SMA Bluetooth Repeater. The Power Modul is only to be employed according
to the information in this manual. Any other application may cause injury to persons or material
damage.
Sunny Boy: Sunny Tripower:
• SB 3000TL-20 • STP 10000TL-10
• SB 4000TL-20 • STP 12000TL-10
• SB 5000TL-20 • STP 15000TL-10
• STP 17000TL-10
No installation of the Power Modul possible in event of the use of RS485
communication.
The Power Modul is to be installed on the slot for modules. The slot can only be fitted with
1 module. If the RS485 communication module (DM-485CB-10) is already installed, you
must decide on one module. If you want to install the Power Modul, you must first remove
the RS485 communication module.
