EmI ENGINEERING SUbmIttAL UNH-t2H-t3H-t4H
factory installed oPtions:
indoor Unit
Power connection:
115-1-60
208/230-1-60
electric Heat:
None
0.75 / 3.0 kW (115/230 Volt)
1.25 / 5.0 kW (115/230 Volt) for UNH24 only
Manufacturer reserves the right to change these specifications at any time without incurring obligation.
oUtdoor Unit:
• Top Condenser Air Discharge Unit
• Independent Circuits, up to four circuits
• Standard Operating Low Ambient in Cooling 32 °F
(0 °C)
• Internally Enhanced Copper Tube/Enhanced
Aluminum Fin Outdoor Coil
• R-22 Refrigerant
• Factory installed Hard Start Assist
• Suction Accumulator (9,000, 12,000, 18,000 Btuh
circuits only)
• Solid Core Filter Drier
• Thermostatically controlled Compressor Crankcase
Heater (9,000, 12,000, Btuh circuits only)
• High pressure control (18,000 and 24,000 Btuh zones)
• Coated Wire Grille Condenser Coil Protection and
Fan Guard
• Five years Limited Compressor Warranty, One year
Limited Parts Warranty
Please use check-box to select Options and Accessories.
oUtdoor Unit
Power connection:
208/230-1-60
condenser coil:
Copper Tube/ Copper Fin
Copper Tube/ Post-Coat Aluminum Fin
standard featUres: –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
indoor Unit:
• Ceiling-Suspended or Floor Console mounted
• Internally Enhanced Copper Tube/Enhanced
Aluminum Fin Indoor Coil
• Unit-mounted, Infrared compatible control package,
configurable to either unit mount or 24 Volt wall
thermostat
• Control programming stored in non-volatile memory
(unit will restart following power failure)
• Indoor coil freeze protection
• Anti-short cycle compressor protection
• Fan purge
• Dry mode for humidity control (requires electric
heat)
• Factory-installed condensate pan overflow
protection
• Factory-supplied molex-type connector for condensate
pump power and control connections
• 24-7 programing
• One year Limited Parts Warranty
oUtdoor Unit
Wind Baffle/Hail guard, architectural
louver Kit
refrigerant line sets
10’
25’
50’
field installed accessories:
indoor Unit
condensate Pump:
48” (1.2 m) Lift
144” (3.7 m) Lift
floor mount trim Kit (Required for Floor
Mount with Condensate Pump accessory)
24 Volt Wall thermostat
infrared Hand-held controller
metal return air grille
