SPECIFICATIONS
1. Data transmission:
8-bit parallel
2. Synchronization:
External supplied STROBE
pulse
3. Handshaking:
Via ACKNLG or BUSY signals
4. Logic level:
TTL level
5. RAM capacity:
32 Kbytes
6. Connector:
57-30360 (Amphenol), 36 pin
or its equivalent
Interface timing
The figure below shows the timing for the parallel
interface.
Figure 3. Interface timing
