Figure 21 - 36 – 24/30/36kVA: Cable Connections
QS4
Modem and
Multicom
power supplies
NEUTRAL (RES/OUT)
W2
U1
PE U V W
N U2 V2
V1W1
PRIMARY
INPUT
GROUND
EXTERNAL
BATTERIES
RESERVE
INPUT
OUTPUT
QS1
FRONT
QS2
E.P.O.
Battery charge
inhibited
QS3
RAU - FEMALE
RS232 - FEMALE
Computer relay
interface - FEMALE
REAR
