CI-9110 6-3
Specifications
Hysteresis:
(Output to gauge) 0.5% of span
Motor Protection:
Adjustable mechanism limits restrict output
for over and under range conditions.
Automatic timeout prevents clutch wear.
Power Failure:
Mechanism maintains output pressure prior
to loss or drop of supply voltage.
6.9 PRESSURE REGULATOR ASSEMBLY
Output Ranges Offered:
Range
Factory Calibrated with
3 - 15 psig
20 psig supply
3 - 27 psig
30 psig supply
6 - 30 psig
35 psig supply
Supply Pressure Range:
Type
Min.
Max.
Unit Supply
Supply
(psig) (psig) (psig)
3 - 15
20
100
3 - 27
30
100
6 - 30
35
100
Supply Pressure Effect:
0.1 psig Max. change in output for each 10
psig change of input.
Connection:
IN, OUT and VENT ports (1/4 Inch NPT)
6.10 INSTRUMENT ENCLOSURE
Type
of
Case:
Weatherproof and explosion proof. Cast
aluminum with gasketed screw-on cover.
Gray epoxy finish. Meets NEMA-3
specifications
General Dimensions:
6 inch (152.4 mm) diameter
7 inch (176.8 mm) length
Weight:
10 pounds (4.54 kg)
Mounting Options:
In-line pressure pipe or 2 inch pipe bracket
6.11 ENVIRONMENTAL
Temperature Limits:
-20° to +150° F (-29° to +65° C) Operating
-40° to +185° F (-40° to +85° C) Storage
