Elo TouchSystems 1767L User Manual
Page 42
C-38 Elo Entuitive Touchmonitor User Guide
17" LCD Touchmonitor (ET17X7L-XXWF-X)Dimensions
NOTES FOR ALL
Material: Wood:
∅4.5 holes thru for M4 screws with nuts or screws for wood ∅4mm.
MOUNTING
Sheet metal: Concealed head threaded studs M4 with nuts.
OPTIONS:
1767L
1747L
R5.4
346
278
338
Viewable
270
Viewable
note:
Add 3.5mm to each measurement for
SecureTouch and Interface
note:
Add 3.5mm to each
measurement for SecureTouch
and Interface
61.2
66.9
4.8
61
67
437
361
338
Viewable
270
Viewable
