3-26 Elo Entuitive Touchmonitor User Guide
EXIT Escape main-OSD
Sharpness Adjusts csharpness.
Phase Controls the vertical and horizontal fine tuning.
Clock Controls the horizontal image size.
OSD Left/Right Adjusts the horizontal position of the OSD menu.
OSD Up/Down Adjusts the vertical position of the OSD menu.
OSD Timeout Determines how long (in seconds) the OSD menu waits before
closing automatically after no action has been performed.
Auto Adjust Automatically selects the optional settings for image parameters
(brightness, contrast, image position, phase etc).Display the current
graphic mode.
Language Selection of the OSD menu language: English, French, German,
Spanish, Japanese.
DSUB Analog/ Select the connection for the display. DSUB Analog(15-pin connector)
DVI Digital or DVI Digital (24-pin connector). In this way you can connect your to
2 computers (by simultaneously using both connectors) and switch
between displays.
