3-25
OSD Menu Function
Function Symbol Process
Contrast Controls the picture contrast
Brightness Controls the picture brightness.
Left/Right Controls the horizontal position.
Up/Down Controls the vertical position.
Recall defaults Recall factory settings of the image parameters.
Color Temperature In this menu you can select one of the default color temperatures (5500
o
K,
6500
o
K, 9300
o
K) Press the OSD button Up and Down or set color values
individually using the "USER" option. To define the color values individually,
select the "USER" option. You can switch between the setting options for
R/G/B (red, green and blue foreground) using the OSD direction button.
Select and specify the desired value by using the OSD button.
A
CONTRAST
A
RGB
RGB
