Polaris 2000 Victory Sport Cruiser - Manual (Page 50)

45
MAINTENANCE
Fuse Replacement
The fuses are located on the right side of the
motorcycle under the right body side cover.
1. To access the fuses, remove seat.
2. Push back the tabs on each side of the
fuse box cover and lift cover off. NOTE:
the cover must be installed with the double
cut-out facing forward.
3. Rotate fasteners 1/4 turn counter
clockwise and lift upward until
disengaged.
Fuse Size for Application
Specified Fuse Size
Main Fuse “A” 10 amp “Blade” type fuse
Main Fuse “B” 20 amp “Blade” type fuse
All other fuses 10 amp “Blade” type fuses
If any fuse is blown, turn off the main switch and determine which fuse is blown.
Install a new fuse of the specified amperage. Turn on the switches and see if the
system operates correctly. If the fuse blows again, see your Victory dealer.
CAUTION Do not use fuses of a higher amperage rating than what is speci-
fied. If the correctly rated fuse continues to blow, something is wrong and needs
to be corrected. Substituting a higher amperage fuse can lead to extensive electri-
cal system damage and possibly a fire.
Fuse Box Diagram
Double Cut-out
IGNITION
RELAY
HEADLAMP
RELAY
ECM
RELAY
TO POWER CORD
10A 20A
10A
10A 10A
FUEL PUMP
RELAY
Fuel Pump ECM
Diode
Starter
Main Ignition
Brake Flasher
Ignition
Horn
Headlamp
