Trinix — Installation and Service Manual 45
Appendix
A
Specifications
Mechanical
Environmental
Air Intake/Exhaust Locations
All modules draw cooling air through fans in the front. Warm air is
exhausted through openings in the back. It is not necessary to leave open
space above or below the chassis.
Table 1. Mechanical Specifications
Depth
, a
a Allow a minimum of 6 in. (152 mm) of clear space at the rear of the MCP for proper cable clearance and air flow.
Width Height Weight
b
b All weights approximate.
Rack Units
TRX-PSFRM-TER-1U 16.25 in./ 483 mm 19.0 in. / 483 mm 1.75 in. / 44 mm 7.2 lb. / 3.2 kg 1
TRX-PSU-1200W 13.85 in. / 351.8 mm 4.0 in. / 101.6 mm 1.66 in. / 42.2 mm 4.616 lb. / 2.1kg 1
Table 2. Environmental Specifications
Environmental Characteristics (operation with required forced air cooling)
Operating temperature 23 to 131 degrees F (-5 to 55 degrees C) ambient
Full specifications met 23 to 131 degrees F (-5 to 55 degrees C)
Storage temperature -40 to 185 F (-40 to +85 degrees C)
