34 Trinix — Installation and Service Manual
Section 1 — Introduction
Software Required
No software changes are required.
Specifications
For mechanical, environmental, and electrical specifications, see
Appendix A-Specifications.
Trinix does not monitor the back-up power supplies. Operation of the
external-back-up power supplies must be checked by monitoring the
power supply status LEDs and Output voltage on the DC-Input connec-
tors. Check the voltage on the DC input connector only at installation to
verify proper connections. After that, you can verify operation with the
LEDs on the front panel of the power supply.
Ordering Information
Table 1. Power Supply Item and Description
TRX-PSFRM-TER-1RU Tertiary Power Supply Chassis for legacy frames.
TRX-PSU-1200W Trinix power supply - 1200W 100-240VAC 50-60Hz
