Discrete LED Test

Selecting

[G - discrete LED test]

from the Diagnostic menu will cause the

screen to appear as in Figure 5-12.

Figure 5-12. Discrete LED Test Menu

Each discrete LED should flash in unison with the others. The flash rate can
be adjusted using any knob.

The purpose of this test is to verify that all the discrete LEDs are
functioning properly.

To stop the test, press any key on the keyboard.

Exit

Discrete LED test . . . Use any knob to adjust flash rate . . .
Press any key to stop the test . . .
