5-13
Menu Diagnostics
Knob Test
Selecting [B - knob test] from the Diagnostic menu will cause the menu
screen to appear as in Figure 5-7.
Figure 5-7. Knob Test Menu
There is one row of data for each of the fourteen knobs on the control panel.
Rotating a knob will cause the data in the row associated with that knob to
change.
The columns identify different components of each knob:
■ Knob ID ÑIdentifying name for a knob
■ Raw Del ÑThe raw delta or change in the knob position (+ or - followed
by 1-3 digits)
■ Filt Del ÑThe filtered delta or change in the knob position, derived from
the raw position (+ or - followed by 1-3 digits)
■ Filt Cumu ÑA cumulative counter, beginning at 0, derived from adding
the filtered delta (four digit hexcode followed by ^ or v)
■ Raw-Delta-2 sec-Min ÑThe minimum value of Raw Del over each 2 second
interval (+ or - followed by 1-3 digits)
■ Raw-Delta-2 sec- Max ÑThe maximum value of Raw Del over each 2
second interval (+ or - followed by 1-3 digits)
■ Raw-Delta-2 sec-Avg ÑThe average value of Raw over each 2 second
interval (- - or | - followed by + or - then 1-3 digits)
The purpose of the test is to verify the range of each knob. If the numbers
change as the knob is moved then the knob is okay. The knob is not
functioning if the numbers stay at 0 or default when the knob is moved.
To stop the test, press any key on the keyboard.
Exit
Testing knobs . . .
Press any key to stop the test . . .
Knob Raw Filt Filt Raw—Delta—2 sec—
ID Del Del Cumu Min Max Avg
MtHue +0 +0 ####^ +3 +3 --+3
MtOpa -0 -0 ####v -5 -5 |--5
MtLum +0 +0 ####^ +3 +3 --+3
MtSat -0 -0 ####v -5 -5 |--5
KyOpa +0 +0 ####^ +3 +3 --+3
KyCan -0 -0 ####v -5 -5 |--5
KyClp +0 +0 ####^ +3 +3 --+3
PnSiz -0 -0 ####v -5 -5 |--5
PnSft -0 -0 ####v -5 -5 |--5
PnWid +0 +0 ####^ +3 +3 --+3
MnSl1 -0 -0 ####v -5 -5 |--5
MnSl2 -0 -0 ####v -5 -5 |--5
MnSl3 +0 +0 ####^ +3 +3 --+3
MnSl4 +0 +0 ####^ +3 +3 --+3
