Epson 5000/5500 - Manual (Page 128)

Commands Arranged by Topic
General operation
ASCII Dec. Hex. Description
ESC @ 64 40 Initialize Printer
ESC U 1/0 85 55 Turn Unidirectional Mode On/Off
ESC EM n 25 19 Control Paper Loading/Ejecting
n = “1” Select bin 1 of CSF
n = “2” Select bin 2 of CSF
n = “R” Eject a sheet
l
For the ESC EM command the variables are the characters
“1” (49 decimal or 31 hex) and “2” (50 decimal or 32 hex).
Do not use 1 decimal, 01 hex, 2 decimal, or 02 hex.
Paper feeding
ASCII Dec. Hex. Description
CR
13
FF 12
LF 10
ESC 0 48
ESC 2 50
ESC 3 n 51
ESC + n 43
0D Carriage Return
0C Form Feed
0A Line Feed
30 Select 1/&inch Line Spacing
32 Select 1/&inch Line Spacing
33 Set n/180-inch Line Spacing
2B Set n/360-inch Line Spacing
Command Summary 8-3
