Epson 5000/5500 - Manual (Page 117)

Printer Specifications
Electrical
120
V model:
Rated voltage:
AC 120 V
Input voltage range:
AC 103.5 to 132 V
Rated frequency: 50
to 60 Hz
Input frequency range: 49.5
to 60.5 Hz
Rated current: 2.0
A
Power consumption:
(during self-test printing in draft mode
at 10 cpi)
ActionPrinter 5000: approx. 33 W
ActionPrinter 5500: approx. 36 W
Dielectric strength (Between AC line and chassis):
AC 1.2 kV, 1 second
220/240
V model:
Rated voltage:
AC 220 to 240 V
Input voltage range:
AC 198 to 264 V
Rated frequency: 50
to 60 Hz
Input frequency range: 49.5 to 60.5 Hz
Rated current:
1.0 A
Power consumption:
(during self-test printing in draft mode
at 10 cpi)
ActionPrinter 5000: approx. 33W
ActionPrinter 5500: approx. 36 W
Dielectric strength (Between AC line and chassis):
AC 1.5 kV, 1 second
Note:
Check
the
label on the back of the printer for the voltage
of your printer.
7-8
Technical Specifications
