13

S-Video input
Input connectors

S-Y/S-C (Common with Component-Pb,Pr)

Standard

NTSC, PAL

Input color format

YPbPr

Color format conversion

YCbCr 4:2:2 12 bits

SD pedestal

0 IRE, 7.5IRE

Audio Input
Input connectors

Balanced analog (2ch)

AES/EBU digital (2ch)

HDMI embedded (8ch)

* HDMI audio is not available when DVI is

chosen for video input.

HDMI / AES sample rate

32 / 44.1 / 48 kHz

Analog ADC sample rate

48 kHz

Sample size

16/20/24 bits

Input level adjust

0dBu +4dBu

* Available for analog audio.

SDI output
Otput connectors

3G/HD/SD-SDI (BNCx2)

* Outputs the same signals.

Output resolution

1080i 60/59.94/50

1080p 60/59.94/50/30/29.97/25/24/23.98

1080PsF 30/29.97/25/24/23.98

720p 60/59.94/50/30/29.97/25/24/23.98

487i 59.94

576i 50

Output color format

YCbCr 4:2:2(ITU-R BT.709/601) 10 bits

* ITU-R BT.601 is in SD resolution.

3G-SDI mapping format

Level A : Direct image mapping

Level B : 2x SMPTE292 HD mapping

Frame freeze function

Supported

* Keep displaying the final frame when there

is no video input signal.

Line 21 closed caption

Not supported
