4 Hardware Settings

4.1 DIP switches

SW1

Specifies the SD pedestal.

OFF: 7.5 IRE

ON: 0 IRE

* Available only for SD-Component, Composite, S-Video input mode.

SW2

Specifies the component level.

OFF: SMPTE/EBU N10

ON: Betacam

* Available for SD-Component input mode.

SW3

Specifies the reference signal source.

OFF: REF (reference signal)

ON: Internal

SW4

Specifies the analog audio input level.

OFF: 0dBu

ON: +4dBu

SW5

SW6

Specifies the up-conversion mode.

SW5=ON

SW6=ON

Convert to 1080p

SW5=ON

SW6=OFF

Convert to 720p

SW5=OFF

SW6=ON

Convert to 1080i

SW5=OFF

SW6=OFF

Through

SW7

SW8

Specifies the display mode.

* See page 9 for details.

SW7=ON

SW8=ON

Reserved

SW7=ON

SW8=OFF

Full screen

SW7=OFF

SW8=ON

Flex view

SW7=OFF

SW8=OFF

Standard
