20 8900NET Instruction Manual
Alarms and SNMP Monitoring
SNMP Trap severity can be one of three degrees:
• Warning – a limitation in the module’s intended performance,
• Alarm – a failure in communication with the module, or
• Informational – a configuration change such as a switch setting.
The enabled SNMP traps will be reported to any SNMP manager that is
identified as an SNMP Report Destination in 8900NET configuration (see
8900NET Module Configuration Web Page on page 34 . Trap severity is
read-only hard-coded information that is interpreted and responded to by
the SNMP Manager software configuration.
The SNMP traps available on the Gecko 8900 frame and modules are out-
lined in
Table 3 . The web page location for the enable/disable controls are
listed as well as the SNMP trap reports available and their severity.
For the latest MIB (Management Information Base) files for the modular
control system, go to the Thomson Grass Valley public ftp site at:
ftp://ftp.thomsongrassvalley.com/pub/modular/
Table 3. 8900 Control System SNMP Traps Summary
Function Web Page Control SNMP Trap Report Trap Severity
8900 Frame Frame Configuration
Frame Bus Status Alarm
Cover Status Warning
Fan Status Alarm
Module Health Alarm
Frame Power Supply 1 and 2 Power Supply Configuration
Power Supply Fault Alarm
Power Supply Removed Warning
8900NET Module 8900NET Configuration
Net Card Status Alarm
Hardware Switch Informational
Media Modules Media Module Slot Config
Slot Fault Alarm
Module Removed Warning
Signal Loss Warning
Reference Loss Warning
