List of Materials

Parts included in your hood

• Hood structure assembly with blower, transition.
• 4 Lamps already installed.
• 1 Grease filter
• 4 Duct covers.
• Hardware bag with:

• Ceiling Mount Template
• Use, care and installation guide
• Wood screws (4 pieces - 3/16" x 1" 3/4)
• Glass Brackets, Springs, Gaskets ( 2 each )
• Assembly screws (70 pieces)
• 4 Plastic Springs
• Duct cover brackets (4 each)

• 8 Vertical supports.
• 2 Upper Ductcover supports.
• 2 Horizontal supports.
• Glass canopy

Optional accessories

• Recirculation KIT
• Charcoal filter

Tools/Materials r

ools/Materials r

ools/Materials requir

equir

equired

• Duct tape
• Wire nuts
• Tape to mount template
• 8" rounded metal duct (lenght to suit installation)
• Measuring tape
• Pliers
• Gloves to protect against sharp edges
• Knife
• Safety glasses
• Electric drill with 5/16" and 3/8" bits
• Strain relief
• Spirit level
• Phillips (Pozidrive) # 2 screwdriver + torx # 2
• Wire cutter/stripper
• Masking tape
• Hammer
• Saw, jig saw or reciprocating saw
