15
EN
Installation and Configuration
Figure 1 – Typical System Configuration
Figure 2 –Assemble bubble ring ass’y (Optional)
Sensor
Alarm Input 1
Alarm Input 2
Alarm Input 3
Alarm Input 4
Alarm Output up to 1
Alarm Output up to 1
Up to 254 cameras
Keyboard
or
or
screw
bubble ring ass’y
