Page 12

12
Drive Shaft Assembly
Level 1
Parts required: POWER BLENDX
TM
14 oz. cartridge
or Lithium-based Grease.
WARNING
Hedge Clipper blades are very sharp. Touching them may lead to
severe personal injury. Avoid touching blades whenever possible,
and always wear gloves to protect hands.
1. Brush loose debris from blade and coat both sides of blade with the
50-50 cleaning mixture.
2. Allow cleaning mixture to soften the remaining gummy residue
then wipe it from the blade.
3. Apply clean oil to the entire length of the blade. Be certain the
blade bolts are lubricated.
4. Wipe excess oil from the blade before putting the unit back in
service.
A
A
Gear Housing
Level 1.
Parts required: POWER BLENDX
TM
14 oz. Cartridge Grease or
Lithium-based Grease.
1. Clean dirt from grease fittings (A).
2. Carefully pump grease in each fitting. DO NOT force grease.
Too much pressure will force grease past seals and cause damage.
Apply 1-2 pumps of grease every 15-25 hours of operation.
