10

1. Hold trimmer firmly and squeeze throttle trigger to accelerate

engine.

2. Tilt trimmer so cutting teeth are angled slightly toward the hedge

or shrub and proceed to cut.

WARNING

Never remove hands from unit when blades are moving.

WARNING

The engine continues running even when the blades have stopped

due to an obstruction. If this occurs, stop the engine, disconnect

ignition cable and remove the obstruction.

roTaTe

CuTTer

assembly

Always use the unit from the right-hand side of your body – NEVER

from the left side. Rotate cutter assembly 180 degrees on driveshaft in

order to avoid cutting directly above your head, and to avoid contact

with hot muffler.

1. Loosen gearcase clamping screw (A), hand guard clamping screw

(B), and remove gearcase locating screw (C).

2. Rotate cutter assembly 180-degrees on driveshaft until locating

hole in driveshaft is visible through locating hole in gearcase.

3. Install gearcase locating screw (C), and securely tighten all hard-

ware.

WARNING

During operation, the complete unit, especially the drive shaft

housing and gearcase may become too hot to touch. Avoid contact

when rotating cutter assembly.

B

A

C

hedge

TrImmIng

WARNING

Hedge Clipper blades are very sharp. Touching them may lead to

severe personal injury. Avoid touching blades whenever possible,

and always wear gloves to protect hands.
