52
APPENDIX
OPTIONAL PARTS
The parts listed below are optionally supplied. When ordering those parts, give the name and Type No. to the sales dealer.
NOTE : Specifications are subject to change without notice.
ON-SCREEN
DISPLAY
RESOLUTION
H-Freq.
(kHz)
V-Freq.
(Hz)
D-VGA 640 x 480 31.47 59.94
D-480p 720 x 480
(Progressive)
31.47 59.88
D-575p 768 x 575
(Progressive)
31.25 50.00
D-SVGA 800 x 600 37.879 60.32
D-XGA 1024 x 768 43.363 60.00
ON-SCREEN
DISPLAY
RESOLUTION
H-Freq.
(kHz)
V-Freq.
(Hz)
D-WXGA 1 1366 x 768 48.36 60.00
D-WXGA 4 1360 x 768 56.16 72.00
D-1035i 1920 x 1035
(Interlace)
33.75 60.00
D-1080i/60
1920 x 1080
(Interlace)
33.75 60.00
D-1080i/50
1920 x 1080
(Interlace)
28.125 50.00
D-WXGA 2 1360 x 768 47.70 60.00
D-WXGA 3 1376 x 768 48.36 60.00
D-720p 1280 x 720
(Progressive)
45.00 60.00
D-WXGA 5 1368 x 768 46.50 50.00
D-SXGA 1 1280 x 1024 63.980 60.020
When a input signal is digital from DVI terminal, refer to chart below.
D-SXGA 2 1280 x 1024 60.276 58.069
Depending on the condition of signals and the type and length of cables, these signals may not be properly viewed.
D-SXGA 3 1280 x 1024 31.650 29.80
1400 x 1050 63.970 60.19 D-SXGA+ 1
D-UXGA 1 1600 x 1200 75.00 60.00
● DVI Board (HDCP Compatible)
Type No. : AH-72003
● 5 BNC Board
Type No. : AH-72015
● Video/Y,C & S-Video Board
Type No. : AH-72023
● D-Sub 15 Board
Type No. : AH-72031
● Network Board Type No. : AH-72142
● Dual SDI Board Type No. : AH-72162
● DVI Board
Type No. : AH-72002
