DATASHEET
DS_Q48SR3R350_12212004

Delta Electronics, Inc.

Delphi Series Q48SR, 165W Quarter Brick Family
DC/DC Power Modules: 48V in, 3.3V/50A out


The Delphi Series Q48SR Quarter Brick, 48V input, adjustable single
output, isolated, open frame DC/DC converters are the latest offering
from a world leader in power systems technology and manufacturing —
Delta Electronics, Inc. This product family provides up to 165 watts of
power or up to 60A of output current in an industry standard footprint.
This product represents the next generation of design technology which
may be utilized to provide high levels of current at very low output
voltages required by today’s leading-edge circuitry. Utilizing an advanced
patented thermal and electrical design technology; the Delphi Series
Q48SR converters are capable of providing higher output current
capability with excellent transient response and lower common mode
noise. Featuring a wide operating output voltage range and high current
at low output voltages, these units offer more useable power over a wide
range of ambient operating conditions. The wide range trimmable output
feature allows the user to both reduce and standardize part numbers
across different and/or migrating voltage requirements. This model
covers the output range of 1.7V to 3.6Vat 50A.

APPLICATIONS

Telecom/DataCom

Wireless Networks

Optical Network Equipment

Server and Data Storage

Industrial/Test Equipment

OPTIONS

Short lead lengths

Non-latching over voltage protection

Negative trim

Positive on/off logic

FEATURES

High efficiency: 91% @ 3.3V/50A

Standard footprint:

57.9x36.8x10.4mm (2.28”x1.45”x0.41”)

Industry standard pin out

Fixed frequency operation

Wide output trim range 1.7V~3.6V

Fully protected: OTP, OVP, OCP, UVLO

No minimum load required

Fast transient response

Start up into pre-biased load

Basic insulation

ISO 9000, TL 9000, ISO 14001 certified

manufacturing facility

UL/cUL 60950 (US & Canada) recognized,

and TUV (EN60950) certified

CE mark meets 73/23/EEC and

93/68/EEC directives

1
