Test System 2000 Release Notes 11
Downloading the TS2000 firmware
The TS2000 code is downloaded into the RAM onboard the CSU chip of
the NCC or TAC element. The CSU RAM remains executable provided
the battery is good and battery supply has not been interrupted. The
Firmware Services dialog box in the TS2000 GUI allows you to:
■
download a selectable version of the code from a selectable directory
■
revert the host element to CSU mode (EPROM code)
■
run selectable versions of the code immediately after download or on
demand
The Select CSU Element dialog box allows you to select the shelf and
slot number of the NCC or TAC for the above activities
Procedure for
downloading
TS2000 firmware (AM2000 must be running in background before you start TS2000.)
1. Start up TS2000 from Windows. The User Authorization dialog box
appears. Enter your name and tab to the password box. Enter your
password and press Return. (The authorized username and password
must have been previously entered in the AM2000 database.)
The TS2000 main display window including the main menu appears
as shown in Figure 3.
