16
TRI TOOL INC.
92-0675 : Rev. 970314
Parts List, Squaring Module Assembly (P/N 82-0126)
Item Part
No. No. Description Qty
NOT SHOWN:
1. 14-0082 SHAFT ASSY, PIVOT 1
2. 24-1047 PLATE, TOP 1
3. 24-1084 PLATE, COVER 1
4. 29-0190 BEARING, THRUST 1
5. 33-0039 SCREW, CAP, 1/4-20 X 5/8" 3
6. 33-0287 SCREW, BUTTON, 1/4-20 X 3/4" 6
7. 33-0499 SCREW, SET, 1/4-20 X 1/4", CUP PT 1
8. 33-0503 SCREW, SET, 1/4-20 X 1/2", CUP PT 7
9. 33-1698 SCREW, FEED 1
10. 33-1735 SCREW, SET, 3/8-16 X 1/4", BRASS TIP 1
11. 34-0108 WASHER, THRUST 1
12. 34-0202 WASHER, THRUST 2
13. 34-0258 WASHER, THRUST 1
14. 35-0345 NUT, FEED 1
15. 41-0148 LEVER ASSY, ADJUSTMENT 1
16. 42-0099 KNOB, FEED 1
17. 47-1184 BRACKET, HINGE 1
18. 49-0216 HOLDER, TOOL 1
33-0995 SCREW, DRIVE, 2 X 3/16" 4
36-0018 WRENCH, T, 1/8" HEX 1
36-0146 WRENCH, COMBINATION, 13/16" 1
