Tri Tool SQM-2AC Squaring Module - Manual (Page 10)

10
TRI TOOL INC.
92-0714 : Rev. 970428
Tighten the hinge bracket by rotating the adjustment lever.
Move the tool bit to the proper position for the diameter of pipe to be machined.
Loosen the (7) set screws to let the tool bit slide.
Slide the tool bit into the desired position.
Tighten the (7) set screw to secure the tool bit.
MACHINING SEQUENCE
Turn the Model 576AC on and let it rotate slowly while ensuring that the tool bit is
not making contact with the end of the pipe.
Bring the motor up to speed.
Turn the feed knob to feed the tool bit into the end of the pipe.
After the face of the pipe has been machined let the tool bit make three more
rotations without feeding to clean up the face.
Back the tool bit off of the pipe by turning the feed knob.
Turn off the motor.
