Model CBM-1 Counterboring Module
92-0192 : Rev. 930618
MAINTENANCE
All components should be cleaned and coated with a light film of oil prior to storage.
Use a clean, non-detergent oil, preferable SAE 10 (90 SSU or lighter).
If the Counterboring Module is operated in such a way that the Module collects chips
or debris near the tool holder, the counterbore module should be cleaned after each
cutting operation.
Daily maintenance
Wipe the unit down and spray with rust preventative under severe humidity
conditions.
Visually inspect for loose screws, missing bolts, or damage due to impact.
Contact Tri Tool if major repair is required.
Tighten or replace screws or other parts as required.
Monthly Maintenance
Thoroughly clean and lubricate the Feed Screw and the Tool Bit Holder.
Feed the Tool Bit Holder out of the Tool Bracket.
With a clean, dry rag, thoroughly wipe down the Tool Bit Holder and the Feed
Screw.
Be sure that all old lubrication, chips, and dirt are completely removed.
Lubricate the Feed Screw and Tool Bit Holder with a light machine oil.
Reassemble the Tool Bit Holder into the Tool Bracket, being sure scribe line
on the Tool Bit Holder is facing the Cover Plate.
