17
Model CBM-1 Counterboring Module
92-0192 : Rev. 930618
Parts List, Counterboring Module (P/N 82-0050)
Item Part
No. No. Description Qty
1. 08-0036 Tool Block Assy (601/602.5SBM) ref
08-0107 Tool Block Assy (602TSB) ref
2. 24-0705 Plate, Top 1
3. 24-0706 Plate, Cover 1
4. 27-0278 Adapter, Mounting ref
5. 29-0211 Bearing, Thrust 1
6. 32-0024 Pin Roll 1
7. 33-0028 Screw, Cap, 10-24 x 1/2 3
8. 33-0060 Screw, Cap, 5/16-18 x 2 1
9. 33-0280 Screw, Button, 10-24 x 5/8 6
10. 33-0487 Screw, Set, 10-24 x 3/16, Cup Pt 1
11. 33-0489 Screw, Set, 10-24 x 5/16, Cup Pt 1
12. 33-0497 Screw, Set, 10-24 x 1 1/4, Cup Pt 1
13. 33-0501 Screw, Set, 1/4-20 x 3/8, Cup Pt 4
14. 33-0510 Screw, Set, 1/4-20 x 1 3/4, Cup Pt 2
15. 33-1512 Screw, Feed, 1/4-40 1
16. 34-0218 Washer, Thrust 1
17. 34-0219 Washer, Thrust 2
18. 42-0100 Knob, Mod, Feed 1
19. 47-0420 Bracket, Tool 1
20. 49-0080 Holder Assy, Tool Bit 1
