GENERAL DESCRIPTION
The CBM-1 C’bore Module is a mechanical accessory for the Tri Tool 601SBM,
602.5SBM and 602TSB Clamshells.
The C’bore Module provides the capability to counterbore pipe after an in-line spool,
valve or fitting has been removed.
The C’bore Module is mounted directly to the Tool Block.
No repositioning or modification of the Clamshell is necessary after in-line spool has
been removed.
The C’bore Module features a manual “easy grip” axial feed and infinitely adjustable
radial positioning.
The C’bore Module utilizes Form Tooling Bits which are available in various standard
configurations.
