OPERATION
Read the operating instructions carefully before attempting to operate the CBM-1
C’bore Module.
Use eye protection at all times when operating the Counterbore Module.
Install the Clamshell on the pipe and remove the in-line spool, fitting etc. as
described in the appropriate Clamshell operating instructions.
Refer to the Operator’s Manual for operation of the 600 Series Clamshell, which is to
be used.
Slide the Mounting Adapter into the Tool Holder.
On Models 601SBM and 602.5SBM the Mounting Adapter is flush with the
back of the Tool Block.
On Model 602TSB the scribe line on the Mounting Adapter should be in-line
with the back of the Tool Block.
Tighten all Tool Holder Set Screws against the Mounting Adapter.
Mount the C’bore Module on the Mounting Adapter.
Secure the C’bore Module to the Tool Block.
Configure the C’bore Module.
Select the appropriate Tool Bit. Refer to the section on Tool Bits.
Use of dull or improperly designed Tool Bits or Tool Bits not manufactured by
Tri Tool Inc. may result in poor performance and may constitute abuse of this
machine and therefore voids the Tri Tool Inc. factory warranty.
Install the Tool Bit in the Tool Bit Holder.
Be sure the cutting edge lies along the radial centerline in the direction of rotation.
Adjust the counterbore diameter.
Radially adjust the C’bore Module using the Feed Sprocket.
