14
TRI TOOL INC.
92-0449 : Orig. 930630
Miter Mandrel Range
Pipe or Tube ID
Jackscrew
Assy
Length
Spacer #1
P/N
Spacer #2
P/N
3.826" to 4.237"
(97.2 mm to 107.6 mm)
33-1740
(1.375" lg)
4.137" to 4.760"
(105.1 mm to 120.9 mm)
33-1741
(1.637" lg)
4.660" to 5.284"
(118.4 mm to 134.2 mm)
33-1742
(1.900" lg)
5.184" to 5.808"
(131.7 mm to 147.5 mm)
33-1743
(2.162" lg)
5.708" to 6.332"
(145.0 mm to 160.8 mm)
33-1744
(2.425" lg)
6.232" to 6.856"
(158.3 mm to 174.1 mm)
33-1740
(1.375" lg)
44-0383
(1.312" lg)
6.756" to 7.381"
171.6 mm to 187.5 mm)
33-1741
(1.637" lg)
44-0383
(1.312" lg)
7.281" to 7.905"
(184.9 mm to 200.8 mm)
33-1742
(1.900" lg)
44-0383
(1.312" lg)
7.805" to 8.430"
(198.2 mm to 214.1 mm)
33-1743
(2.162" lg)
44-0383
(1.312" lg)
8.329" to 8.954"
(211.6 mm to 227.4 mm)
33-1744
(2.425" lg)
44-0383
(1.312" lg)
8.854" to 11.052"
(224.9 mm to 280.7 mm)
33-1743
(2.162" lg)
44-0384
(2.625" lg)
10.952" to 11.577"
(278.2 mm to 294.1 mm)
33-1744
(2.425" lg)
44-0384
(2.625" lg)
*11.477" to 12.390"
(291.5 mm to 314.7 mm)
33-1743
(2.162" lg)
44-0383
(1.312" lg)
44-0384
(2.625" lg)
*Note: To achieve this range with the specified Jackscrew and Spacers:
the shorter Spacer (P/N 44-0383) must be screwed into the Miter Mandrel Head
and then the longer Spacer (P/N 44-0384) screwed into the top of the first Spacer
(P/N 44-0383).
Mounting Dimensions
JACKSCREW ASSEMBLIES
AND SPACERS
