www.desatech.com 108860-01D 35
PARTS LIST
MODELS (V)T32EN, (V)T32ENb, (V)T32ENR, (V)T32ENRb, (V)T32EP, (V)T32EPb, (V)T32EPR
AND (V)T32EPRb
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts
on page 28 of this manual.
(V)T36EN, (V)T36EP
(V)T36ENR, (V)T36EPR
T36ENb, T36EPb
T36ENRb, T36EPRb
VT36ENb, VT36EPb
VT36ENRb, VT36EPRb DESCRIPtION qtY.
____
108080-0 108080-01 Rear Refractory Brick Panel 1
____
108081-0 108081-01 Top Refractory Brick Panel 1
____
10808-0 10808-01 Right Refractory Brick Panel 1
____
108083-0 108083-01 Left Refractory Brick Panel 1
PART NUMbER
KEY
NO.
(V)T36EN
(V)T36EP
(V)T36ENb
(V)T36EPb
(V)T36ENR
(V)T36EPR
(V)T36ENRb
(V)T36EPRb DESCRIPtION
qtY.
1 ** ** Firebox Assembly 1
** ** Face Weldment 1
3 108010-01 108010-01 Door Assembly (T Models Only) 1
108010-0 108010-0 Door Assembly (VT Models Only) 1
4 108687-01 108011-01 Top Louver Assembly 1
5 108687-0 108011-0 Bottom Louver Assembly 1
6 108015-01 108015-01 Fireplace Top 1
7 108016-01 108016-01 Fireplace Top Insulation 1
8 ** ** Fireplace Surround 1
9 108074-03 108074-03 Burner Assembly (Natural Gas) 1
108074-04 108074-04 Burner Assembly (Propane/LP Gas) See pages 36 & 37 1
10 108076-01 108076-01 Burner Base Gasket 1
11 see below see below Rear Refractory Brick Panel (B Models Only) 1
1 see below see below Top Refractory Brick Panel (B Models Only) 1
13 see below see below Right Refractory Brick Panel (B Models Only) 1
14 see below see below Left Refractory Brick Panel (B Models Only) 1
15 11418 11418 Push-On Nut
16 1105 1105 Screen
17 108719-01 108719-01 Screen Rod 1
18 1413 1413 Strain Relief 1
19 1171 1171 Gas Knock-Out Cover
0 4353 4353 Handy Box Assembly 1
1 4460 4460 Gas Conduit Assembly 1
10908-01 10908-01 Heat Shield 1
3 109006-01 109006-01 Log Set 1
3-1 109007-01 109007-01 Rear Log (Log 1) 1
3- 11018-01 11018-01 Front Log (Log ) 1
3-3 109008-01 109008-01 Crossover Log (Log 3) 1
3-4 107347-01 107347-01 Right Log (Log 4) 1
3-5 109009-01 109009-01 Base Log (Log 5) 1
3-6 107348-01 107348-01 Left Log (Log 6) 1
PARTS AVAILAbLE - NOT SHOWN
5487 5487 Lava Rock/Bag Assy 1
753 753 Notice Label 1
5540 5540 Vent Label 1
** Not a field replaceable part.
