10.
Snap on crimp insulators 11.
Slide silicone caps over crimp insulators.
13.
Completed splice kit. Make sure latch
mechanism is in the locked position.
14.
To remove cap, lift latch mechanism and
unscrew cap.
12.
Tighten cap securely.
Terminator TM ZS/ZE
INSTALLATION PROCEDURES
In-Line Splice
Wiring Details
