6
Specifications
Frequency Band to Antenna 5725~5850 MHz
Frequency Band to Radio 2400~2500 MHz
Local Oscillator Frequency 3328 MHz
Frequency Stability 2.5 ppm
Transmit Output Power (5.8GHz) 500 mW (27dBm)
Input Power (2.4GHz) 0.5 mW ~ 25 mW
Transmit Gain 14dB
Maximum Receiver Input Level -20dBm
Noise Figure 4.0 dB Max.
Receive Gain 14 dB
Input Filter 5725~5850 MHz
Output Filter 2400~2500 MHz
Rx Switching Time <1 µS
LED indicators on UDC Tx: Green, Rx: Red
Operating Temperature -40 °C ~ + 70 °C
Power Supply 9.0V DC at 0.8 amp
RF Connector Type N, Female
UDC5800 Dimensions 3.75” L X 6” W X 1.2” H
DC Injector Dimensions 3.5” L X 3” W X 1.18” H
UDC5800 Weight 2.0 lb
DC Injector Weight 0.4 lb
/
Caution
Do not exceed 200mW (+23 dBm) of input power to the UDC.
2.4/5.8 GHz Channel Conversion Table
.
802.11
Channel
2.4 GHz
(MHz) 5.8 GHz (MHz)
1 2412 5740
2 2417 5745
3 2422 5750
4 2427 5755
5 2432 5760
6 2437 5765
7 2442 5770
8 2447 5775
9 2452 5780
10 2457 5785
11 2462 5790
.
