Figure 6: top hardware platform, Figure 7: bottom hardware platform, Figure 8: bottom/top smt526 – Sundance DVIP User Manual
Page 9
SITE 1
SMT362
SITE 2
SMT526
SITE 4
SMT339
SITE 3
Figure 6: Top Hardware platform
The SMT339 can be use on SITE 2. Nevertheless, to use the RSL it’s easier to use the
SMT526 (RSLÙRSL) with the SMT339 SITE 4 as shown figure 6.
Figure 7: Bottom Hardware platform
Figure 8: Bottom/Top SMT526
User Manual for DVIP
Page 9 of 11
Last Edited: 30/09/2009 14:51:00
