Top Primary TIM Connector

Bottom Primary TIM Connector

SHB

B

SHB

A

RSL

B

RSL

A

Po
we
r

SMT391

TIM 3.3V

TIM 3.3V

Holes mounted with

Nylon screw (M2x10) and

4 Nylon nuts (M2)

SMT338-VP

Holes mounted with

Nylon screw (M2x10) and

4 Nylon nuts (M2)

a – First, fit two Nylon screws (M2x10), pointing out (the head of the screws

on bottom side).


User Manual SMT8091

Page 11 of 16
