1.0 Introduction
Thank you for selecting a SunPumps PCC-BT series solar pump system. The PCC-BT series pump
controller is a key component to high quality solar powered pumping systems. Their stand-alone, pollution
free and low noise operation makes them an ideal solution for remote homes, irrigation projects, and
wildlife and stock watering without violating the environment.
The PCC-BT series controllers are microprocessor based solid state DC power converters designed as the
interface between a solar module array and a brush type DC pump motor. The purpose of the controller is
to operate the high efficiency, high reliability DC motor and maximize the total daily water output while
providing protection for the pump as well as providing an interface with other related pumping system
equipment and accessories.
Although these PCC-BT series pump controllers are easy to install, please read this manual to
become familiar with the controller features, functions, connection points and various configurations.
For future reference, keep this manual and other relevant product information in a safe place.
PRECAUTIONS

Safety First – Always understand what you are doing when working with any form of
electricity. Guessing may cause product damage and/or severe personal injury.

Shut down all power when working on the system.

Do not attempt to feed live wires into the PCC-BT series controller. Product damage and/or
personal injury may result.

Do not exceed the voltage rating of the controller.

Do not splash water on the controller when the cover is open.

Mount the controller in a shaded, well vented, vertical position.

Installation of this system should be done by a licensed Pump Contractor.
2.0 Product Overview
The SunPumps PCC-BT series controllers were designed for brush type DC motors. When properly
installed and configured, the unique features incorporated into this stand-alone system will automatically
control and protect your pump system permitting longer dependable, trouble free service. The controller is
designed for an open circuit voltage up to 300 volts DC with a recommended nominal voltage from 30 to
no greater than 220 volts DC. The nominal voltage of the system should be sized according to the desired
pump voltage and power. The controller has various settings for the maximum current and will be
discussed later in this manual.
