Model 76DA/77 User Guide Issue 2, April 2011
Studio Technologies, Inc. Page 11
for Surround
For compatibility with AES3id unbalanced
digital audio signals connect the D-sub’s
+ terminal as signal high, and both the
– and shield terminals as the signal low/
shield. When terminating to a BNC plug the
D-sub’s + terminal should connect to the
center pin; the – and the shield connec-
tions should go to the “body” of the BNC
plug. To clarify, for optimal operation it is
best to connect both the – and shield con-
nectors together directly on the D-sub plug,
rather than at the BNC end of the interface
assembly. Note that the output circuitry is
transformer-coupled so it is possible to just
connect to the + and – terminals and still
experience correct operation. This would
leave the shield connection unterminated.
Refer to Figure 4 or Appendix A for the
exact connection details. Note that unlike
a DA-88-style assembly, the two threaded
fasteners associated with the Model 76DA’s
D-sub connectors use 4-40 threads. This
complies with the original design standard
for D-subminiature connectors.
Pre-Fader Surround Digital Monitor
Output
The pre-fader surround digital monitor
output channels are intended to connect
to metering, measurement, or other signal
monitoring equipment that requires un-
interrupted, full-level digital audio signal
sources.
Stereo Input C Direct Digital Monitor
Output
The stereo input C direct digital monitor
output is intended for use in site-specific
applications. It provides an uninterrupted,
full-level digital audio signal source that
is post-SRC and input delay in the signal
chain.
Post-Fader Surround Digital Monitor
Output
The post-fader surround digital monitor
output channels are designed for connec-
tion to digital inputs on audio amplifiers
associated with monitor loudspeakers.
Alternately, they could be connected to the
inputs of loudspeakers that contain inte-
grated amplifiers with digital audio input
capability.
Post-Fader Stereo Digital Monitor
Output
The post-fader stereo digital monitor out-
put channels are intended to support a
stereo loudspeaker system, either by con-
necting to the digital input of an amplifier
associated with a set of loudspeakers or
directly to a set of amplified speakers that
provide digital inputs.
Analog Monitor Outputs
The connector labeled Analog Monitor
Outputs provides access to the Model
76DA’s 6-channel (5.1) surround and
TASCAM® Signal Signal
Connections Channel High (+) Low (–) Shield
Pre-Fader L/R 1 24 12 25
Pre-Fader C/LFE 2 10 23 11
Pre-Fader LS/RS 3 21 9 22
Stereo Input C Direct 4 7 20 8
Post-Fader L/R 5 18 6 19
Post-Fader C/LFE 6 4 17 5
Post-Fader LS/RS 7 15 3 16
Post-Fader Stereo 8 1 14 2
Notes: 1) All signals transformer-coupled digital audio;
selectable for AES3 or AES3id compatibility.
2) Connector type on Model 76DA is 25-pin
D-subminiature female (DB-25F). Installer must
provide male (DB-25M). Connector uses 4-40
threaded inserts for locking with mating plug.
3) Wiring scheme follows TASCAM DA-88 convention.
Standard DA-88-type wiring harnesses are directly
compatible, with the possible exception of 4-40 screw
threads being required.
Figure 4. Connections for Digital Monitor Outputs
