30
EXPLODED VIEW AND PARTS LIST (CONTINUED)
Parts List of Deck Total Ass’y (continud)
LOC PART S/N PART NAME PART DISCRIPTION
DRUM AS
D0010 DRUM AS REFERRING TO LIST OF DRUM PRICE ASS’Y
D0030 97SA324400 DRUM M/T AS E20XL-25
D0030 97SA327100 DRUM M/T AS DMVDMTO4M
D0040 7001260711 SCREW MACHINE PAN 2.6X7 MFZN
D0050 97SA320400 EARTH GROUND AS T-DRUM
D0060 97S2303600 HOLDER MAIN POM(KEPITAL F20)
D0070 97S2303700 HOLDER CAP(A) POM(2CH)
D0070 97S2303800 HOLDER CAP(B) POM(4CH)
D0070 97S2303900 HOLDER CAP(C) POM(6CH)
AD002 7051300611 SCREW MACHINE PAN 3X6 SW MFZN
DECK AS
AM001 DECK AS REFERRING TO LIST OF DECK TOTAL ASS’Y
A0100 97SA318100 MAIN BASE AS T-MECHA
A0200 97SA316500 S SLANT POLE AS T-MECHA
A0300 97SA316600 T SLANT POLE AS T-MECHA
A0400 97S8101600 MOTOR CAPSTAN DMVCMC07DR
A0400 97S8101600 MOTOR CAPSTAN NEW SANVIC
A0500 97S3102000 SCREW TAPPTITE TT2 BIN-P 2.6X7 MFZN
A0600 97SA320500 AC HEAD AS HVMXB1000AK
A0600 97SA326800 AC HEAD AS HVMXA1101A
A0700 7051300611 SCREW MACHINE PAN 3X6 SW MFZN
A0800 97SA316800 L LOADING AS T-MECHA
A0900 97SA316900 R LOADING AS T-MECHA
A1000 97S2709500 RACK LOADING SECC T1.2
A1100 7008301911 SCREW MACHINE WAS M3*19 MFZN
A1200 97S0904300 PLATE CONNECT SECC T0.8
A1300 97SA319400 REEL BRKT TOTAL AS T-MECHA
A1400 7274300611 SCREW TAPPTITE TT3 RND 3X6 MFZN
A1500 97S5500400 BELT REEL CR68
A1600 97S2623200 LEVER RELAY SECC T1.2
