NOZZLE ASSEMBLY PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1* 16-920-03 O-Ring 1
2* 16-920-05 Diaphragm Teflon (Optional) 1
3* 16-920-06 Diaphragm EPDM Rubber (Standard) 1
4* 16-798 Chemsaver End Cap 1
5 16-800 Gasket Viton 1
6 16-921 Cap 1
7 15-588 Turbo Turf Jet Tip #8 1
* 16-996 Body 1
Optional 33-550 10 Mesh Brass Strainer
Optional 33-551 20 MEsh Brass Strainer
When the 16-920-05 Teflon Diaphragm is used, it is placed in the assembly in front of the
16-920-06 EPDM Rubber Diaphragm. Nozzles are located 20" (51 cm) apart on the right, left,
and center tubes . There are predrilled holes in all tubes. The Nozzle should be at a 45° angle
to the ground for proper application.
