13
Diagrams
WIRING PARTS LIST
REF # PART # DESCRIPTION QUANTITY
1 12-003 Toggle Switch (part of 42-302 Kit) 1
15-472 Switch Boot 1
2 50-359 Oil Pressure Warning Light 1
3 12-017 Hour/ Volt Meter Combo 1
4 13-488 Ignition Switch (B & S# 496603) 1
76-310 Key Set (comes with 13-488) 1
5 14-272 Seat Switch 1
6 76-327 Ground Battery Cable 1
7 Battery (not included)
8 75-518 Battery Cable 1
9 42-252 Wire, Circuit Breaker to Solenoid 1
10 8975 30 Amp Circuit Breaker 1
8977 Circuit Breaker Boot 1
11 13-492 Solenoid (B & S# 807829) 1
12 22-017 Cable Black 1
13 Starter (on engine) 1
14 13-491 Oil Sender (on engine B & S# 491657) 1
15 Stop Switch Terminal (on engine) 1
16 Rectifier (on engine) 1
17 After Fire Solenoid (on engine) 1
18 76-260 Ground Wire (part of 42-302 Kit) 1
19 42-118 Electric On/Off Valve (part of 42-302 Kit) 1
42-763 Wire Harness (includes all wire colors with *) 1
