75
Accessories
42-010 CONSTRUCTION LEVELING BLADE PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HB-12-13-500 Bolt 1 /
2
- 13 x 5 4
HNTL-12-13 Lock Nut 1 /
2
- 13 4
2 42-015 Attachment Mount 2
*3 42-203 Attachment Lift 1
*4 HB-38-16-100 Bolt 3 /
8
- 16 x 1 5
HNTL-38-16 Lock Nut 3 /
8
- 16 5
*5 HCP-12-200 Clevis Pin 1 /
2
x 2 2
*6 HHP-18 Bridge Pin 1 /
8
3
*7 HCP-58-250 Clevis Pin 5 /
8
x 2 1 /
2
1
8 18-154 Rod End 1
*9 42-097 Leveling Blade 1
10 42-217 Cylinder Mount 1
11 18-168 90° Elbow 2
12 HCP-34-175 Clevis Pin 3 /
4
- 1 3 /
4
1
13 10-135 Hydraulic Cylinder 1
* 42-010 Construction Leveling Blade (all other parts are reference only)
INSTALLATION INSTRUCTIONS
1. Remove the cylinder mount (Ref 10) from the machine.
2. Bolt leveling blade (Ref 9) to attachment lift (Ref 3) using five 3 /
8
- 16 x 1 bolts and five 3 /
8
- 16 lock nuts as
shown on drawing.
3. Attach the attachment lift to attachment mount (Ref 3) using clevis pin and bridge pin (Ref 5 and 6).
4. Lift attachment lift up or extend cylinder so rod end (Ref 8) lines up with the holes on the center of the
attachment lift. Use 5 /
8
x 2 1 /
2
clevis pin and bridge pin (Ref 6 & 7) to fasten cylinder to cultivator.
5. Turn machine on and test for proper operation.
