103
Accessories
26-007 PROFESSIONAL INFIELD FINISHER PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 Rear Axle (part of main frame) 1
2 42-024 Rake Lift 1
3 HP-18-100 Cotter Pin 1 /
8
x 1 1
4 HCP-12-150 Clevis Pin 1 /
2
x 1 1 /
2
1
5 HB-58-11-300 Bolt 5 /
8
- 11 x 3 2
HNCL-58-11 Center Lock Nut 5 /
8
- 11 2
6 13-365 Drawbar 1
7 26-045 Leveling Screen 1
8 HCP-12-450 Clevis Pin 1 /
2
x 4 1 /
2
1
9 HMB-12-14 Machine Bushing 1 /
2
x 14GA 1
10 19-107 Hitch 1
11 HHP-18 Bridge Pin 1 /
8
1
INSTALLATION INSTRUCTIONS
The Professional Field Finisher is used for smoothing and leveling fields to professional standards.
1. Attach leveling screen (Ref 7) to drawbar (Ref 6) using two bolts (Ref 5) and center lock nuts.
2. Attach hitch (Ref 10) to drawbar (Ref 6) using clevis pin (Ref 8), machine bushing (Ref 9) and a cotter
pin (Ref 3).
3. Mount Professional Field Finisher to the hitch on the trap rake with a clevis pin (Ref 4) and bridge pin
(Ref 11).
4. Hook chains from finisher to rake lift arms.
5. NOTE: When assembled properly, rake will angle down from front to back. If front of finisher is not
higher than the back, damage will result to infield.
42-185 DRAG MAT KIT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 Main Frame 1
2 HB-38-16-225 Bolt 3 /
8
- 16 x 2 1 /
4
4
3 42-186 Right Mat Carrier 1
4 13-157 Strap 2
5 HWL-38 Lock Washer 3 /
8
4
6 HN-38-16 Nut 3 /
8
- 16 4
7 42-024 Rake Lift (part of machine) 1
8 19-605 Drag Mat Chain 1
HHP-18 Bridge Pin 1 /
8
1
9 42-187 Left Mat Carrier 1
10 19-601 Steel Mat 1
INSTALLATION INSTRUCTIONS
1. Looking from the rear of the Super Star, mount the mat carrier posts (Ref 3 & 9) outside the rear corner of
the rake lift with the straps (Ref 4) on the inside of the rake lift side plate. Bolt into place with 3 /
8
- 16 x 2 1 /
4
bolts, lockwasher and nuts.
2. To carry the Drag Mat, roll it up and place it in the brackets of the mat carriers.
3. To us the Drag Mat, unroll the mat flat and hook it up to the Super Star hitch with the clevis pin in the
chain and the bridge pin provided.
