Accessories
42-008 SAND CULTIVATOR PARTS LIST
REF# PART# DESCRIPTION QTY
1 HCP-58-175 Clevis Pin 5 /
8
- 1 3 /
4
1
2 10-135 Hydraulic Cylinder 1
3 18-168 90° Elbow 2
4 42-217 Cylinder Mount 1
5 HB-12-13-500 Bolt 1 /
2
- 13 x 5 4
HNTL-12-13 Lock Nut 1 /
2
- 13 4
6 42-015 Attachment Mount 2
*7 HHP-18 Bridge Pin 1 /
8
3
*9 HB-38-16-125 Bolt 3 /
8
- 16 x 1 1 /
4
10
HNTL-38-16 Lock Nut 3 /
8
- 16 10
*10 42-038 Tine Segment 5
*11 HCP-12-200 Clevis Pin 1 /
2
x 2 2
*12 42-203 Attachment Lift 1
*13 HCP-58-250 Clevis Pin 5 /
8
x 2 1 /
2
1
14 18-154 Rod End 1
* 42-008 Sand Cultivator (all other parts reference only)
INSTALLATION INSTRUCTIONS
1. Install valve handle with linkage (13-672) onto valve.
2. Remove the cylinder mount (Ref 4) from the machine.
3. Tine Segments (Ref 10) should be bolted to the attachment lift (Ref 12). Attach the attachment lift to (Ref
12) attachment mount using (Ref 11 & 7) clevis pin and bridge pin.
4. Lift attachment lift up or extend cylinder so rod end (Ref 14) lines up with the holes on the center of the
attachment lift. Use clevis pin and bridge pin (Ref 7 and 13) to fasten cylinder to sand cultivator.
6. Turn machine on and test for proper operation.
