75
Accessories
13-199 EDGER KIT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HCP-12-150 Clevis Pin, 1 /
2
x 1 1 /
2
2
2 HHP-18 Bridge Pin, 1 /
8
2
3 13-200 Edger Frame 1
4 HB-12-13-150 Bolt 1 /
2
- 13 x 1 1 /
2
2
HW-12 Washer 1 /
2
2
HWL-12 Lockwasher 1 /
2
2
HN-12-13 Nut 1 /
2
- 13 2
5 13-203 Spindle Tube 1
HG-14-28-180 Grease Fitting 1 /
4
- 28 x 180° 1
6 21-169 Bearing & Collar 2
7 13-206 Spindle Shaft 1
8 13-205 1 /
2
Disc Flange 1
9 13-204 Disc 1
10 HMB-34-14 Machine Bushing 3 /
4
x 14GA 2
11 HWL-34 Lockwasher 3 /
4
1
12 HNA-34-16 Axle nut 3 /
4
- 16 1
13 HP-18-150 Cotter Pin 1 /
8
x 1 1 /
2
1
14 HB-38-16-100 Bolt 3 /
8
- 16 x 1 1
HWL-38 Lockwasher 3 /
8
1
HW-516 Washer 5 /
16
1
HW-716 Washer 7 /
16
1
15 Attachment Lift (Part of Lift Assembly)
16 Main Frame (Part of Trap Rake)
INSTALLATION INSTRUCTIONS
Optional Lift Assembly 13-505 must be installed before installing this unit on Super 2
1. For initial assembly, bolt spindle tube (Ref 5) to edger frame (Ref 3) at a 60° to 70° angle. Use bolts,
washers and nuts (Ref 4).
2. Next, make sure 1 /
2
" thick by 3 1 /
2
" round spacer (Ref 8) is on spindle shaft up to shoulder. Then place
disc (Ref 9) onto the shaft followed by two 3 /
4
machine bushings (Ref 10), one 3 /
4
lockwasher and one 3 /
4
- 16 axle nut (Ref 12). Tighten nut and use 1 /
8
x 1 1 /
2
cotter pin (Ref 13) to lock it.
3. The edger unit mounts under the center of trap rake, fastening to attachment lift assembly, 13-146.
4. Start engine and lower attachment lift FULLY. Stop engine.
5. Slide edger unit under trap rake from right side.
6. Position lift brackets (pockets) of edger on lift bars, both sides at once or one side at a time if only one
person is working on this.
7. Start engine again and raise lift bars until horizontal with ground. Stop engine.
8. Slide edger frame arms forward until holes of arms match rear holes of attachment bracket on main
frame of trap rake. Secure them with two each; 1 /
2
x 1 1 /
2
clevis pins and 1 /
8
bridge pins.
9. Start engine and test lift and edger to make sure that all works well.
10. To remove edger, lower lift until horizontal, undo the clevis and bridge pins, and slide edger off lift arms.
Use CAUTION when releasing unit so it will not come down to fast on anyone’s toes, fingers or legs.
